NEW S35C Stroke Harvester
The harvesting head you have been waiting for! The all new S35C will cut timber up to a maximum diameter of 42cm / 16”. The delimbing stoke is 50cm and with 40kN force it will delimb up to a maximum branch diameter of 35cm / 13 ¾”.
£26,000 + vat (introductory offer price)
Click image for photo gallery
Description
The harvesting head you have been waiting for! The all new S35C will cut timber up to a maximum diameter of 42cm / 16” with a new design chainsaw bar of 59cm / 23 ¼” length. The delimbing stoke is 50cm and with 40kN force it will delimb up to a maximum branch diameter of 35cm / 13 ¾”. The Naarva S35C also comes as standard with Blue Tooth length measuring and a 7” wireless tablet display. Diameter measuring is an optional extra.
Like all Naarva stroke harvesters there are no wires or additional hydraulics required on the crane / excavator as all functions of the Naarva S35C are operated by the open / close function usually used for the timber grab.
The Naarva S35 harvesting head weighs 340Kg, requires a hydraulic flow of 50to 70 litres per minute, 180-210 bar, and is suitable for cranes mounted base units or tractors and 8–13-ton excavators.
Video(s)
Naarva S35C harvesting head - prototype
Photo gallery
